BRAVO COMPACT

Are you working with limited space? DropsA’s BRAVO COMPACT features the same high-performance technology as our original BRAVO grease pump, but in a smaller package.

Designed for mobile machinery, this progressive lubrication system can accommodate up to three pumping elements, withstand a maximum pressure of 350 bar, and perform optimally even in rugged, demanding environments.

SKU: N/A Category:

Description

  • IP69K Rating: This compact pump is engineered to withstand temperature extremes (-40 degrees Celsius to 80 degrees Celsius/-40 degrees Fahrenheit to 176 degrees Fahrenheit).
  • Remote Monitoring & Setting: The BRAVO COMPACT is equipped with a smart, CAN-bus-compatible controller that lets you easily adjust settings and monitor performance in real time.
  • Level Notification: This smart pump comes with a built-in sensor that notifies you when oil levels are low.
  • Easy-to-Use App: This pump can be easily controlled using our proprietary app, which works even without an Internet connection.
  • Compact Without Compromise: Despite its small size, the BRAVO COMPACT delivers precise lubrication even in heavy-duty applications.
  • Adjustable Flow Rate: You can customize a pumping rate from 0.6 to 4 cc/min, depending on application needs.
  • Flexible Setup: BRAVO COMPACT operates on a 12/24 V AC/DC power supply, offering multiple voltage options for your setup.

Additional information

Maximum Pressure

350 bar

Flow Rate

0.6 to 4cm/3min

Lubricant

NLGI 2

Temperature

-40 to 80 degrees Celsius/-40 to 176 degrees Fahrenheit

Relative Humidity

90%

Reservoir Size

,

Voltage

,

Connector Position

Right side

Outlet

Nr 3 G 1/4”

Threaded Connection

Nr 2 1/8” side holes and 1/4” front hole

Connector

7 pin bayonet connector

Description Type

Mini-Display Controller and CAN-Bus, IP69K, Grease Pump, Mini-Display Controller, IP69K, Grease Pump
